560cc Maxi Sport Scooter
With its high performance engine, motorcycle style chassis and scooter convenience, the original TMAX stunned the two-wheeled world back in 2001. Available for just one year, the Special Edition TMAX 25th Anniversary gives every maxi-scooter rider the chance to pay tribute to an icon.
Take a look
- Electrically adjustable screen
- Heated grips and heated seat
- Rider’s aids
- 560cc EURO5+ compliant engine
- Re ned body and headlight
- 7-inch TFT screen with Garmin Navigation
- Enhanced connectivity
- Comfortable ergonomics
- Machined wheels
- Lightweight aluminium frame
- Large storage space
Max is in details
Inspired by the first ever TMAX Special Edition from 2006, the TMAX 25th Anniversary features a premium quality double stitched seat with a unique red cover as well as a red 25th Anniversary 3D logo and special Black MAX badge. The body is finished in an exclusive Dark Grey Metallic finish with a red chrome TMAX 3D badge, beautifully contrasted by Light Grey Metallic boomerangs and black wheels with machined rims.
Iconic, stylish and original, the TMAX has forever changed the way hundreds of thousands of riders choose to live their lives – and many customers have been TMAX fans right from the beginning. With its exclusive colours and unique detailing, the TMAX 25th Anniversary enables you to be a part of the rich history of this much-loved Sport Scooter.
Technical specifications
| Engine type | 4-stroke, Liquid-cooled, DOHC, 4-valves, Parallel twin-cylinder |
| Displacement | 562 cc |
| Bore x stroke | 70.0×73.0 mm |
| Compression ratio | 10.9:1 |
| Maximum power | 35.0 kW @ 7,000 rpm |
| Maximum torque | 55,0 Nm @ 5250 rpm |
| Lubrication system | Dry sump |
| Fuel system | Fuel Injection |
| Ignition system | TCI |
| Starter system | Electric |
| Transmission system | V-Belt Automatic |
| Fuel consumption | 4.8 L/100 km |
| CO2 emission | 112 g / km |
| Front suspension system | Telescopic forks |
| Front travel | 120 mm |
| Rear suspension system | Swingarm |
| Rear travel | 117 mm |
| Front brake | Hydraulic dual disc brake, Ø267 mm |
| Rear brake | Hydraulic single disc brake, Ø282 mm |
| Front tyre | 120/70R15M/C 56H Tubeless |
| Rear tyre | 160/60R15M/C 67H Tubeless |
| Overall length | 2.195 mm |
| Overall width | 780 mm |
| Overall height | 1.415 mm – 1.470 mm(adjustable windscreen) |
| Seat height | 800 mm |
| Wheelbase | 1.575 mm |
| Minimum ground clearance | 135 mm |
| Wet weight | 219 kg |
| Fuel tank capacity | 15 L |
|
Screen type |
TFT |
|
Screen size |
7-inch |
|
Smartphone Connectivity |
MyRide Link |
|
On-screen Navigation |
Garmin Motorize |
