Take a look
- M1-style aerodynamic bodywork
- High-efficiency EU5 998cc engine
- High quality finish with a new two-tone paint
- KYB 43mm front fork
- Brake Control System (BC)
- Engine Brake Management (EBM) system
- State-of-the-art LED headlights and position lights
- APSG ride-by-wire throttle
- Launch Control System (LCS)
- high friction brake pads
- Bridgestone Battlax RS11 tires – 190mm wide rear
- TFT instrument displays with EBM and BC
The history of the R range. Your future.
Every high-tech component used in the R1 has been developed from knowledge gained as a result of Yamaha’s involvement in top-level racing. Its incredible 998cc EU5 crossplane four-cylinder engine is a direct descendant of the M1, while its aerodynamic bodywork is a direct result of racing developments.
But most of all, what makes the R1 such an incredibly special bike is its incredible selection of smart electronics. With complete equipment, from ride-by-wire accelerator to launch control system (LCS), engine brake management (EBM) or brake control (BC), among many other things, this is Yamaha’s supercar definitive, created to exert a natural leadership in the street or in circuit. Additionally, it is available in a sporty two-tone color scheme, Icon Blue with Matte Blue, as well as dynamic Yamaha Black.
Technical specifications
Engine type: 4-stroke, Liquid-cooled, 4-cylinder, DOHC, 4-valve
Displacement: 998cc
Bore x Stroke: 79.0×50.9mm
Compression ratio: 13.0 : 1
Maximum power: 147.1 kW (200.0 hp) at 13,500 rpm
Maximum torque: 113.3 Nm (11.6 kg-m) at 11,500 rpm
Lubrication system: Wet sump
Clutch type: Wet, Multi-disc
Ignition system: TCI
Starting system: Electric
Drive system: Constant engagement, 6-speed
Final Drive: Chain
Approved consumption: 6.8 l/100 km
CO2 emission:159 g/km
Carburettor: Electronic fuel injection
Chassis: Aluminum Deltabox, Diamond
Advance angle of the pivot: 24th
Pivot lead: 102 mm
Suspension system: front
Telescopic: fork
Rear suspension system: link type suspension, swing arm
Front Travel: 120mm
Rear travel: 120mm
Front brake: Double hydraulic disc, Ø 320 mm
Rear brake: One hydraulic brake disc, Ø 220 mm
Front tire: 120/70 ZR17M/C (58 W), tubeless
Rear tyre: 190/55 ZR17M/C (75 W), tubeless
Total length: 2055 mm
Total width: 690 mm
Total height: 1165 mm
Seat height: 855 mm
Wheelbase: 1405mm
Minimum ground clearance: 130 mm
Weight (including full oil tank and fuel tank): 201 kg
Fuel tank capacity: 17 l
Oil tank capacity: 4.9 l
