2024 XMAX 300 Tech MAX
With its excellent performance combined with dynamic good looks and class leading functionality, the high specification XMAX 300 Tech MAX is the clear choice for anyone looking for the ultimate riding experience. And now Yamaha is taking this Sport Scooter to the next level with a fully new model that offers you even more.
Take a look
- Engine Type 4-stroke, Liquid-cooled, SOHC, 4-valves, Single cylinder
- Displacement 292cc
- Bore x Stroke 70.0 × 75.9 mm
- Compression Ratio 10.9:1
- Maximum Power 20.6 kW @ 7,250 rpm
- Maximum Torque 29.0 Nm @ 5,750 rpm
- Starter System Electric
- Transmission V-Belt Automatic
- Lubrication System Wet sump
- Clutch Type
- Ignition System TCI
- Final Transmission
- Fuel Consumption 3.0 l / 100 km
- CO2 Emissions 70 g / km
- Fuel System Fuel Injection
Engineered to the MAX
Equipped with high-tech 4.2-inch full colour TFT instruments featuring a multi-theme infotainment screen, this premium Sport Scooter gives you smartphone connectivity. It’s easy to receive messages and emails, select music and much more – and for stress-free highway commuting and relaxed weekend cruising, XMAX 300 Tech MAX is equipped with a new Garmin compatible navigation system.
The dynamic angular body design with its new X-shaped front lighting gives the XMAX 300 Tech MAX an even more radical and distinctive look – and new shape 3D boomerang side covers reinforce the pure MAX DNA. Featuring dedicated colours as well as exclusive aluminium footplates, a special finish on body parts and a leather style seat cover, this is the smart way to go.
Technical specifications
Engine type: 4-stroke, Liquid-cooled, SOHC, 4-valves, Single cylinder
Displacement: 292 cc
Bore x Stroke: 70.0×75.9mm
Compression ratio: 10.9:1
Maximum power: 20.6 kW @ 7,250 rpm
Maximum torque: 29.0 Nm @ 5,750 rpm
Lubrication system: wet sump
Fuel system: Fuel injection
Ignition system: TC|
Starting system: Electric
Transmission system: Automatic V-belt
Approved consumption: 3.0L/100km
CO2 emission: 70g/km
Front suspension system: Telescopic fork
Front travel: 110 mm
Rear suspension system: oscillating unit
Rear travel: 79 mm
Front brake: Hydraulic single disc brake, Ø 267 mm
Rear brake: Single disc brake, Ø 245 mm
Front tire: 120/70-15
Rear tire: 140/70-14
Total length: 2,185 mm
Total width: 775 mm
Total height: 1,415 mm (adjustable screen 1,465mm)
Seat height: 795 mm
Distance between axis: 1,540 mm
Minimum ground clearance: 135 mm
Weight (including full oil tank and fuel tank): 180kg
Fuel tank capacity: 13L
