Nmax 125

Now is the time to rethink the way you get around town, and the NMAX 125 is Yamaha’s vision of a new personal mobility. With a dynamic and economical EURO5 compliant Blue Core 125cc engine, which can travel approx. 300km on one tank of fuel, this easy-to-ride commuter scooter packs a premium finish and high specification at an affordable price.

Take a look

  • Motor Blue Core compliant with EURO5 of 125 cc
  • sporty body design
  • Communications Control Unit (CCU)
  • Sistema Smart Key
  • High rigidity chassis
  • traction control system
  • Start & Stop function
  • Storage space under the seat
  • Larger LCD instruments
  • Power outlet and front pockets
  • Front and rear disc brakes with ABS

the city and you

The sporty and dynamic bodywork of the NMAX 125 features stylish front and rear LED lights, and an aerodynamic fairing that offers better protection against wind and rain. The chassis offers better maneuverability in city traffic, and the simple ergonomics make this the most comfortable way to get around.

Plus, you’ll be amazed at the high-tech built-in as standard. The NMAX 125’s new Communication Control Unit (CCU) links via Bluetooth with your smartphone to give you access to important information. Plus, features like Smart Key keyless ignition, power outlet and under-seat storage will make your day-to-day easier.

Technical specifications

Engine type: 4-stroke, Liquid-cooled, SOHC, 4-valve


Displacement: 125 cc


Bore x Stroke: 52,0 × 58,7 mm


Compression ratio: 11.2:1


Maximum power: 9,0 kW (12,2 PS)/8000 r/min


Maximum torque: 11,2 Nm (1,1 kgf/m)/6000 r/min


Lubrication system: Wet sump


Fuel system: Fuel injection


Ignition system: TC|


Starting system: Electric


Transmission system: Automatic V-belt


Approved consumption: 2.2L/100km


CO2 emission: 52g/km

Front suspension system: Telescopic forks


Front travel: 100mm


Rear suspension system: Oscillating unit


Rear travel: 85mm


Front brake: hydraulic single disc brake


Rear brake: hydraulic single disc brake


Front tire: 110/70-13M/C 48P tubeless


Rear tire: 130/70-13M/C 63P sin tube

Total length: 1935 mm


Total width: 740 mm


Total height: 1160 mm


Seat height: 765 mm


Distance between axis: 1340 mm


Minimum ground clearance: 125 mm


Weight (including full oil tank and fuel tank): 131kg


Fuel tank capacity: 7.1L
