TMAX Tech MAX

You work hard. You risk to win. For you, time is money. And you know how to appreciate authenticity and quality. So when you see everything the TMAX Tech MAX has to offer, you know this is probably one of the easiest and smartest decisions to make in a long time.

Take a look

  • Powerful 560cc EURO5 engine
  • Dynamic and sporty body design
  • Projected beam headlights with integrated turn signals
  • Improved ergonomics for rider and passenger
  • Full map navigation on the connected TFT screen
  • Electric adjustable windshield
  • Cruise control
  • Heated grips and seat
  • Premium, best-in-class specifications
  • Keyless operation via Smart Key
  • Ultralight aluminum chassis
  • Sophisticated electronic control technology
  • Great load capacity
  • Central stand with anti-theft lock

Aspire to the MAX

Europe’s best-selling sport scooter has been radically improved with a best-in-class 7-inch TFT color display and full smartphone connectivity to keep you connected on every ride. The full-map Garmin navigation system* makes sure you’re there on time, and with heated seat and grips, electric display and cruise control, you’ll be able to enjoy world-class comfort year-round. (*Garmin full map navigation requires a subscription contract which is not available in all countries. Some navigation features are not available in all countries, check with Garmin for availability.)

The TMAX Tech MAX also features a compact body with a longer seat and footrests for even more ride comfort. Its aggressive front end and aerodynamic front wings create a supersports bike-inspired look that brings the TMAX Tech MAX closer to the world of motorcycles. Meanwhile, premium components and a class-leading finish confirm what you probably already knew about this iconic machine.

Technical specifications

Engine type: 4-stroke, Liquid-cooled, DOHC, 4-valve, Parallel twin-cylinder


Displacement: 562cc


Bore x Stroke: 70.0×73.0mm


Compression ratio: 10.9:1


Maximum power: 35.0kW @ 7500rpm


Maximum torque: 55.7Nm at 5250rpm


Lubrication system: Dry sump


Fuel system: Fuel injection


Ignition system: TC|


Starting system: Electric


Transmission system: Automatic V-belt


Approved consumption: 4.8L/100km


CO2 emission: 112g/km

Front suspension system: Telescopic fork


Rear suspension system: Swing arm


Front Travel: 120mm


Rear travel: 117mm


Front brake: Hydraulic double disc brake, Ø 267 mm


Rear brake: Hydraulic single disc brake, Ø 282 mm


Front tire: 120/70R15M/C 56H tubeless


Rear tire: 160/60R15M/C 67H tubeless

Total length: 2195mm


Total width: 780mm


Total height: 1,415 mm – 1,525 mm (electric screen)


Seat height: 800mm


Distance between axis: 1575mm


Minimum ground clearance: 135mm


Weight (including full oil tank and fuel tank): 220kg


Fuel tank capacity: 15L
