YZ250F Monster Energy Yamaha Racing Edition
Official Yamaha riders are always fighting for the podium at every MX2 World Grand Prix. With a special inverted-head engine and a lightweight aluminum frame, the YZ250F has proven to be one of the best bikes in the category. And with its unique black bodywork and factory-style graphics, the very special YZ250F Monster Energy Yamaha Racing Edition is the ultimate factory-style 250cc 4-stroke.
Take a look
- Monster Energy Yamaha Racing Edition Bodywork
- Class-leading suspensions
- Lightened cycle part components
- Championship winning engine design
- Wide rear wheel and tire
- Handlebar-mounted 2-mode mapping switch
- Brake caliper with large diameter pistons
- Aluminum double beam chassis
- Easy to use Power Tuner app
The piloting starts here.
With your YZ250F Monster Energy Yamaha Racing Edition you can be sure you have one of the best-performing front and rear suspension sets in its class, combined with an agile aluminum chassis designed with a careful balance of rigidity to offer the best behavior.
For maximum efficiency, the YZ250F’s 250cc 4-stroke engine features a special front intake intake and rear exhaust exhaust for instant response and race-winning acceleration. And with the easy-to-use Power Tuner app, you can adjust your bike’s power at the trackside to suit track conditions. The pedaling starts here.
Technical specifications
Engine type: 4-stroke, Liquid-cooled, DOHC, 4-valve, Single cylinder
Displacement: 250cc
Bore x Stroke: 77.0×53.6mm
Compression ratio: 13.8:1
Lubrication system: Wet sump
Clutch type: Wet, Multi-disc
Ignition system: TCI
Starting system: Electric
Drive system: 5 speeds, Constant shot
Final Drive: Chain
Carburetor: Electronic fuel injection
Chassis: Semi-double crib
Pivot lead angle: 26° 50
Pivot advance: 119mm
Front suspension system: Inverted telescopic fork
Rear suspension system: Swing arm, link type suspension
Front Travel: 310mm
Rear travel: 317mm
Front brake: Hydraulic disc, Ø 270 mm
Rear brake: Hydraulic disc, Ø 240 mm
Front tire: 80/100-21 51M with camera
Rear tire: 110/90-19 62M with camera
Total length: 2175mm
Total width: 825mm
Total height: 1285mm
Seat height: 970mm
Distance between axis: 1475mm
Minimum ground clearance: 335mm
Weight (including full oil tank and fuel tank): 106kg
Fuel tank capacity: 6.2L
Oil tank capacity: 0.95L
